Grafana: Integrating Alert With Email And Slack
![Grafana: Integrating Alert With Email And Slack](/content/images/size/w2000/2024/07/Frame-8-3.png)
In this tutorial, we will explore how to configure Slack and email for alert notifications in Grafana. We will cover how to integrate Slack using an API token or a Webhook URL and set up email notifications to ensure you receive alerts promptly. Properly configuring alert notifications is essential for maintaining a responsive and well-monitored Grafana instance.
Configuring Slack
There are two primary methods for integrating Slack with Grafana: using a Slack API token or a Webhook URL. Each method has distinct advantages and is suited for different use cases. For this tutorial, we will be using Slack API token.
Creating a Slack App and Requesting Scopes
To start, create a Slack app by visiting the apps page and selecting the Go to Your Apps button. On the Your Apps page, choose Create an App.
![Create app screen in grafana](https://blog.elest.io/content/images/2024/07/Screenshot-2024-07-17-at-12.06.47-PM.jpg)
Then click on From scratch, enter a name for your app, such as Elestio Grafana Demo and select the workspace where you will be developing your app. You can distribute your app to other workspaces later if needed. Click Create App to finalize the process.
![Naming App in grafana](https://blog.elest.io/content/images/2024/07/Screenshot-2024-07-17-at-12.10.40-PM.jpg)
If you need to update your app's name later, you can do so from the Home tab under Basic Information. Note that this change will update the bot name, which is the name that appears when the app performs actions like posting in a channel or sending direct messages.
After creating your app, the next step is to request the necessary scopes, which give your app permission to perform specific actions within your workspace. By default, Slack apps cannot post to public channels. They need explicit permission through scopes. Request the chat:write.public
scope to enable your app to post in all public channels without joining them.
![Scopes in grafana](https://blog.elest.io/content/images/2024/07/Screenshot-2024-07-17-at-12.16.08-PM.jpg)
To request scopes, navigate to OAuth & Permissions and scroll down to the Scopes section. Under Auth Tokens click on Install to Workspace.
![Installing OAuth token in grafana](https://blog.elest.io/content/images/2024/07/Screenshot-2024-07-17-at-12.17.42-PM.jpg)
Once installed copy the Bot User OAuth Token to a safe place. Additionally, head over to your Slack workplace, right-click on the channel you want to get alerts on, click View Channel Details, View Channel Details and scroll down to find Channel ID. Copy this ID as it will be required in the next steps.
![Bot token in grafana](https://blog.elest.io/content/images/2024/07/Screenshot-2024-07-17-at-12.18.52-PM.jpg)
To allow your app to access public Slack channels, add the channels:read
scope. By configuring these scopes, your app will have the necessary permissions to interact effectively within your Slack workspace.
Configuring Grafana for Slack Notifications
To set up Slack notifications in Grafana, navigate to Alerts -> Alerting -> Contact points. Click + Add Contact Point and name to your contact point, and choose Slack from the Integration list.
- For API token integration: Enter the copied Channel ID in the Recipient field and the Bot User OAuth Token in the Token field.
- For Webhook URL integration: Paste the Webhook URL into the Webhook field.
![Configuring grafana for slack notification](https://blog.elest.io/content/images/2024/07/Screenshot-2024-07-17-at-12.34.49-PM.jpg)
Test the integration to confirm its functionality and then save the contact point.
Configuring Email
In addition to Slack, you can configure email as a contact point in Grafana to ensure that you receive alerts via email as well. Follow these steps to set up email notifications:
- Navigate to Contact Points: Go to Alerts & IRM -> Alerting -> Contact points in Grafana.
![Alerting tab in grafana](https://blog.elest.io/content/images/2024/07/Screenshot-2024-07-17-at-12.01.48-PM.jpg)
- Add a Contact Point: Click on "+ Add contact point."
![Contact points screen in grafana](https://blog.elest.io/content/images/2024/07/Screenshot-2024-07-17-at-12.05.25-PM.jpg)
- Name Your Contact Point: Enter a name for the contact point, such as Elestio Trial Mail.
![Creating email contact point in grafana](https://blog.elest.io/content/images/2024/07/Screenshot-2024-07-17-at-12.06.28-PM.jpg)
- Configure Email Settings:
- Addresses: Enter the email addresses where you want to receive alerts. You can add multiple addresses separated by commas.
- Subject: Define a subject template for the email notifications.
- Body: Customize the body of the email to include relevant alert information.
- Test the Integration: Click the Test button to ensure the email configuration is working correctly.
Assigning the Contact Point to Alerts
Once the Slack contact point is configured, it needs to be added to your alert rules. Go to Alerting -> Alert rules in Grafana. Click on the New alert rule to head over to the alert rule.
![Alert rules in grafana](https://blog.elest.io/content/images/2024/07/Screenshot-2024-07-17-at-12.38.52-PM.jpg)
Edit or create a new alert rule, and navigate to the Configure labels and notifications section. Under Notifications, select the contact point you created from the drop-down menu, save the rule, and exit. This step is similar for both Slack and Email integrations.
![Configuring labes and notification in grafana](https://blog.elest.io/content/images/2024/07/Screenshot-2024-07-17-at-12.40.13-PM-1.jpg)
Thanks for reading ❤️
Setting up both Slack and email as contact points in Grafana ensures you have robust and reliable alert notifications. By following the steps outlined, you can configure these integrations to keep you informed of any critical alerts, whether through Slack messages or email notifications. This multi-channel approach enhances your monitoring setup, providing greater flexibility and ensuring you never miss important alerts.
